ETERNUS DX900 S6 and ETERNUS DX8900 S6

Figure: Rear View of a Controller Enclosure (ETERNUS DX900 S6 and ETERNUS DX8900 S6)

  1. Controllers (CM#0, CM#1)

    (Refer to Controllers.)

  2. Host interfaces (CA#0, CA#1, CA#2, CA#3)

    (Refer to Host Interface.)

  3. Drive adapter (DA#0, DA#1)

    (Refer to Drive Adapter.)

  4. BUD (BUD#0, BUD#1)

    (Refer to BUD.)

  5. Power supply units (CPSU#0, CPSU#1)

    (Refer to Power Supply Units.)

  6. FRT port (FRT#0, FRT#1, FRT#2, FRT#3)

    This port is used to connect CMs and FRTs.

  7. FST (LAN) port

    A port that is dedicated for maintenance engineers. Customers must not use this port.

  8. RMT (LAN) port

    This port is used for connecting a LAN cable and used for separating the network (such as for the remote support) from the MNT port for operation management. This port uses an RJ-45 connector.

  9. MNT (LAN) port

    This port is used for connecting a LAN cable and used for operation management. This port uses an RJ-45 connector.

  10. SVC port (SVC#0, SVC#1)

    This port is used to connect CMs and SVCs.
