Power Distribution Units (1U)

The 1U power distribution unit has four outlets and two inlets.

Figure: Power Distribution Units (1U)

1. Main line switch

   This turns on and off the power distribution unit.

2. Outlet (OUTPUT)

   This is a socket (IEC60320 C13) for outgoing power supply. This socket is used to connect a power cord (AC output cable).

3. Inlet (INPUT)

   This is a socket (IEC60320 C14) for incoming power supply. This socket is used to connect a power cord (AC input cable).
