Power Synchronized Connections (Wake On LAN)

By using Wake On LAN, an instruction to power on the ETERNUS DX can be issued via the LAN.

"Magic packet" is sent by the utility software for Wake On LAN. The ETERNUS DX detects this packet and the power is turned on.

Figure: Power Supply Control Using Wake On LAN

Powering on sequence

  1. A power on instruction is issued to the ETERNUS DX via the LAN.

  2. ETERNUS DX startup

Note

"Magic packet" is sent to all the controllers that are connected to the LAN.
