Power Distribution Unit (AC16A/200V, 2U, 16 Outlets)

There are 16 outlets.

Figure: Power Distribution Unit (AC16A/200V, 2U, 16 Outlets)

  1. Main line switch

    This turns on and off the power distribution unit.

  2. Outlet (OUTPUT)

    This is a socket (IEC60320 C13) for outgoing power supply. This socket is used to connect a power cord (AC output cable).

The specifications of a power distribution unit and the power cords that are provided are shown below.

Table: Power Distribution Unit (AC16A/200V, 2U, 16 Outlets) and Provided Power Cord Specifications

Item

Specifications

Power

Voltage

AC 200 – 240V

Phase

Single

Frequency

50Hz/60Hz

Input cable

Connection type

Straight-through n NEMA L6-20P

Length

4m

Quantity

2
