Power Distribution Unit (AC8A/200V, 1U, 4 Outlets)

There are four outlets and two inlets.

Figure: Power Distribution Unit (AC8A/200V, 1U, 4 Outlets)

  1. Main line switch

    This turns on and off the power distribution unit.

  2. Outlet (OUTPUT)

    This is a socket (IEC60320 C13) for outgoing power supply. This socket is used to connect a power cord (AC output cable).

  3. Inlet (INPUT)

    This is a socket (IEC60320 C14) for incoming power supply. This socket is used to connect a power cord (AC input cable).

The specifications of a power distribution unit and the power cords that are provided are shown below.

Table: Power Distribution Unit (AC8A/200V, 1U, 4 Outlets) and Provided Power Cord Specifications

Item

Specifications

Power

Voltage

AC 200 – 240V

Phase

Single

Frequency

50Hz/60Hz

Input cable

Connection type

IEC60320 C13 n NEMA L6-15P

Length

3m

Quantity

2
