ETERNUS DX900 S6 and ETERNUS DX8900 S6

Figure: Controller (ETERNUS DX900 S6 and ETERNUS DX8900 S6)

The LEDs turn on or blink to indicate the statuses that are listed below.

Table: Status and Meaning of Each LED (Controller for the ETERNUS DX900 S6 and ETERNUS DX8900 S6)

LED name

LED status

Meaning

READY/FAULT

(green)

The controller is in normal status.

(blinks green)

An error has occurred during startup.

(amber)

  • The controller is in error status.

  • An error has occurred during startup.

(blinks amber)

IDENTIFY

(blinks blue)

The installation location of the controller is identified according to the instruction that is issued from ETERNUS Web GUI or ETERNUS CLI.

LAN LINK

(green)

The link between the LAN port and the destination port has been established.

LAN ACT

(blinks green)

Data is being sent or received via the LAN port.

MAIN CM

(green)

The controller is set as a Main CM.

CA READY/FAULT

(green)

The link between the CA port and the destination port has been established.

(amber)

The CA port is in error status.

DA READY/FAULT

(green)

The link between the DA port and the destination port has been established.

(amber)

The DA port is in error status.

(blinks amber)

The ports to connect the cables are indicated. This occurs while a drive enclosure is being added.

BUD READY

(green)

The BUD is in normal status.

BUD FAULT

(amber)

The BUD is in error status.

FRT READY/FAULT

(green)

The FRT is in normal status.

(amber)

The FRT is in error status.

SVC READY

(green)

The SVC is in normal status.

SVC FAULT

(amber)

The SVC is in error status.
